TEAC's devotion to sound quality, recognized by professionals the world over, started in the era of reel-to-reel tape. Today, TEAC have fused their passion for sound with the latest network audio features and state of the art audio technology.

As the first model in the Reference 7 Series, TEAC invested the NR-7CD Network CD player/ Integrated amplifier with all the high-resolution playback expertise that TEAC has accumulated over the decades through the development of high-end and pro audio equipment.

From high-resolution master audio sources, including DSD 5.6MHz and PCM 384kHz/32-bit, to the classic albums sleeping in the corner of your CD library, and from the vast collections of music provided by premium loss-less quality on-line music subscription services such as TIDAL and qobuz on Internet, to high-quality wireless music streaming via Bluetooth®, this unit can handle them all in style.

Despite being multifunctional in nature, this is a no-compromise device. Every stage, from the D/A converters to the power amplifier section, it employs a dual monaural circuit design, and every audio signal is processed on fully-balanced circuit from the beginning to the end. The RDOT-NEO is remarkable, that up-converts incoming digital audio signal including conventional CD to DSD12.2MHz or PCM 384kHz which is Hi-Res audio quality, while free control app TEAC HR Streamer provides look-and-feel operation on you r smartphone/tablet.

Highly-experienced craftsmen undertake the entire process from soldering to assembly. With a "Made in Japan" label comes immense attention to detail, as well as a level of sound quality thats appropriate for the flagship of TEAC's Reference Series.

The TEAC sound, which has been recognized in professional audio environments over the decades, and a design that embraces this accumulated history, have been successfully fused into this all-in-one Network CD player/Integrated amplifier for a new era.

Features

• All-in-One solution incorporating Integrated Amplifier, Network Player and CD Player
• OpenHome network supporting DSD5.6MHz and PCM384kHz/32-bit via LAN
• Supporting premium music subscription services, TIDAL and qobuz on Internet (*1)
• Built-in Bluetooth® receiver with LDAC, Qualcomm® aptX, AAC and SBC codec
• Centre-mounted TEAC-made CD mechanism
• Coaxial and optical digital inputs supporting DSD input (DoP format)
• Hi-Res audio playback from USB flash memory
• NEW VINTAGE design in A3-size footprint
• Dual peak meters and an organic EL display
• Precision machined aluminum knobs with high-precision bearings
• Full stage dual monaural circuit design
• Dual D/A converters for left and right channels by VERITA AK4490
• Up-convert from conventional CD to DSD11.2MHz/PCM352.8kHz (DSD 12.2M/PCM384kHz for 48kHz incoming signal)
• RDOT-NEO (Refined Digital Output Technology NEO) employing Fluency algorithm
• TEAC-OVCS (Octa Volume Control System) for precise volume control
• Robust chassis design and construction
• Dual power amplifier modules by ICEpower deliver 230W + 230W
• AMAC (Aluminum-block Mounted Amplifier Construction) for simplified analog signal paths
• TEAC-HCLD headphone amplifier delivering 500mW+500mW
• 3.5mm 4-polar headphone jack supporting GND separate drive
• Custom EI-core power transformers with 2-way windings
• 4 digital filters
• Dual on-board clocks for 44.1kHz and 48kHz systems incoming digital signal
• Isolated Digital/Analog circuit design
• 3-position patent-registered Pin-point feet
• Large gold-plated binding-post speaker terminals
• Gold-plated RCA jacks
• Detachable IEC power socket and OFC power cord

Technical Specifications

Please click here to view the Datasheet
