Product Overview & Specifications
The latest iteration of the Michell Engineering Gyro represents a ground-up engineering overhaul of an iconic analogue design. Retaining its legendary silhouette, the new Gyro transitions from traditional cast aluminum to a precision-machined 19 mm aerospace-grade aluminum tooling plate main chassis. Optimized using AI-modeled structural vibration control, the chassis incorporates integrated brass counterweights to balance tonearm assemblies and foam damping inserts around the arm mount to prevent energy reflections from reaching the stylus.
Engineering upgrades extend across the entire mechanical framework: an aluminum baseplate replaces the legacy acrylic Spider frame, resting on large Sorbothane™ isolation feet. The signature suspended sub-chassis is re-tuned to a 3.5 Hz resonant frequency featuring Equilibria™ lateral damping, while the inverted main bearing introduces a double-helix oil-pumping mechanism that doubles lubrication flow. Powered by a freestanding motor pod machined from solid aluminum billets, the fully grounded system features electronic speed control and a sleeker platter profile with an eliminated belt groove.
KEY FEATURES & PROPRIETARY TECHNOLOGIES
- 19 mm Machined Aerospace Aluminum Chassis: Precision-milled tooling plate chassis featuring AI-modeled structural optimization, integrated brass counterweights, and arm-mount foam damping inserts.
- Re-Tuned Suspension with Equilibria™ Damping: Suspended sub-chassis architecture tuned to 3.5 Hz with Equilibria™ lateral damping to eliminate rotational staggering.
- Double-Helix Oil-Circulating Inverted Bearing: Inverted main bearing with an upgraded double-helix pumping design delivering twice the lubrication flow rate over previous generations.
- Aluminum Baseplate Framework: Solid aluminum baseplate replacing the original acrylic Spider frame for increased rigidity and resonance isolation.
- Shielded Freestanding Motor Pod & Electronic PSU: Freestanding motor unit and power supply machined from solid aluminum billets with complete RF shielding, grounding, and electronic speed selection.
- Refined Platter & Precision Coupling: Smooth-edged platter with hidden drive belt pathway paired with precision metal tonearm coupling (replacing legacy Delrin spacers).
- Sorbothane™ Isolation Feet: Heavy-duty Sorbothane™ dampening feet designed to isolate the entire deck from room vibrations and mechanical feedback.
SPECIFICATIONS
| Product Category | Reference Manual Suspended Turntable |
| Chassis Construction | 19 mm Machined Aerospace-Grade Aluminum Tooling Plate with Brass Counterweights |
| Baseplate Frame | Solid Machined Aluminum Baseplate (Replaces Acrylic Spider) |
| Suspension Architecture | 3-Point Suspended Sub-Chassis (3.5 Hz Resonant Frequency) with Equilibria™ Lateral Damping |
| Main Bearing Type | Inverted Oil-Circulating Bearing with Double-Helix Pumping (2x Flow Rate) |
| Motor System | Freestanding Billet Aluminum Motor Pod & Electronic Power Supply Unit |
| Speed Control & Selection | Electronic Speed Control (Fully Grounded & RF Shielded) |
| Platter Style | High-Mass Platter with Smooth Edge (Grooveless Belt Pathway) |
| Tonearm Mounting | Direct Precision Coupling Plate with Integrated Foam Reflection Damping |
| Isolation System | Large Sorbothane™ Vibration-Damping Isolation Feet |
| Country of Origin | Handcrafted in the United Kingdom (Michell Engineering) |
