Gustard R30 Discrete R2R 27BIT Network Streaming DAC
Gustard R30 Discrete R2R 27BIT Network Streaming DAC
Our price match promise...
If you find an identical item cheaper from one of our online competitors, tell us and not only will we match the price, we'll beat it by 10% of the difference.
Estimated Shipping Widget will be displayed here!
This reference-grade Network DAC & Streamer features a discrete R2R DAC topology alongside a dedicated Sony 1-Bit Direct DSD conversion circuit. Equipped with K2 Technology ultra-low noise clock synthesis, an integrated Roon Bridge network streaming engine, and support for 10M master clock inputs, it delivers exceptional dynamic range, ultra-low distortion, and superior channel separation for high-end digital audio systems.
KEY FEATURES
- 10M Master Reference Clock Input: Accepts external 10MHz master clock inputs for ultra-precise timing synchronization.
- K2 Technology Ultra Low Noise Clock Synthesizer: Eliminates digital jitter and timing artifacts across all digital inputs.
- Discrete R2R DAC: Uses a precision resistor ladder network for continuous, natural, and highly detailed analog reconstruction.
- Sony 1-Bit Direct DSD Conversion Circuit: Dedicated hardware path for pure 1-bit direct DSD decoding without PCM conversion.
- Roon Bridge Network Streaming: Built-in multi-protocol network module supporting hi-res streaming across home networks.
- Discrete 8-Channel Hybrid I/V Stage: Fully discrete hybrid current-to-voltage power conversion circuit designed specifically for the R2R architecture.
SPECIFICATIONS
| Supported LAN Protocols | Roon, AirPlay, UPnP, NAA, Spotify (Configurable, Online Upgradeable) |
| LAN Speed | 100 / 1000 Mbps |
| 10M Clock Input (BNC) | 50Ω, 0 dBm – 20 dBm, CMOS 0.2V–3.3V, Sine Wave 0.5V–3.3V |
| Frequency Response | 20 Hz – 20 kHz (±0.2 dB) |
| Dynamic Range | >123 dB |
| Signal-to-Noise Ratio (SNR) | >121 dB |
| Channel Crosstalk | -139 dB @ 10 kHz |
| Total Harmonic Distortion + Noise (THD+N) | ≤0.00145% @ 1 kHz |
| Intermodulation Distortion (IMD) | ≈0.002% @ -1 dBFS |
| RCA Line Output | 2.5 Vrms (Fixed), 100Ω Output Impedance |
| XLR Balanced Output | 5.1 Vrms (Fixed), 100Ω Output Impedance (Pin 1 GND, Pin 2 Hot, Pin 3 Cold) |
| Power Supply Requirement | AC 115V / 230V (50/60 Hz) |
| Power Consumption | <30 W |
| Dimensions (W × D × H) | 430 × 300 × 80 mm (94 mm Height with Feet) |
| Package Dimensions | 530 × 400 × 180 mm |
| Total Weight | 10 kg (Including Packaging) |
