The all new LS5/5f delivers an additional 5Hz of bass extension within +/-2dB. In-room, it certainly sounds more like 10hz of additional bass extension. There is noticeably more bass than its stand-mount sibling, though still the maintaining the LS5/5's wonderful bass texture.

According to the BBC's research, the addition of the slots around the woofers, allowed the speakers to perform as a narrower source, creating a wider horizontal dispersion pattern and resultant sweet spot. Improved vertical dispersion also made the speakers easier to position in a room.

The slots also make the speakers easier to position in a room. Because these speakers were originally designed for engineers to monitor the audio signal behind a long mixing console, the speakers have a broad sweet spot. Off-axis listening is perfectly coherent.

These remarkable speakers deliver Midrange Magic in spades, without sacrificing any resolution in the process.

The LS5/5f is 16" taller than the regular LS5/5. It will be available in oak, cherry, rosewood, walnut, or ebony. Partial grills (covering the drivers) will be available in off-white, brown, or black. Fasteners can be requested in black, stainless steel, or gold plated.


Specification of Graham Audio LS5/5f speaker :

• System - 3-way reflex loading
• Enclosure - Thin Wall Damped construction, floor standing
• Recommended Amplifier power - 50 200 watts unclipped program
• Sensitivity - 88dB/2.83v/1m
• Maximum Output - Over 104dB for a pair at 2m
• Nominal Impedance - 8 ohms
• Response - 35Hz-20kHz +/-2dB
• Crossover point - 400Hz, 3.5kHz
• Dimensions - 111 h x 36 w x 48cm d 43.7 x 14.9 x 18.9
• Weight 46Kgs / 101 lb.
• Connectors - Gold plated terminals
• Bass - Long Throw 300mm / 12
• Midrange - 200mm / 8
• HF - 25mm Soft Dome Tweeter / 1

Manufacturer Site

• Graham Audio
