Product Overview & Specifications
Delivers a dramatically rich and detailed sound designed to captivate your senses. Prepare yourself for true musical indulgence and a beautiful design that will grace any home.
KEY FEATURES
- Patented SMC Technology: Features Soft Magnetic Composite (SMC) at the heart of the magnet motor system to drastically minimise coloration and distortion.
- In-House Woofers: Latest-generation wood fibre-based drivers developed and manufactured at production facilities in Denmark.
- Multilayer Laminate Enclosure: Constructed from 6 layers of MDF to form a rigid cabinet that reduces resonances, paired with a curved form factor that practically eliminates standing waves.
- Hybrid Tweeter System: Optimised specifically for the EPICON series to deliver exceptionally smooth and wide horizontal dispersion.
SPECIFICATIONS
| Specification | Detail |
|---|---|
| Frequency Range (±3 dB) | 35Hz – 30,000Hz |
| Sensitivity (2.83V/1m) | 89 dB |
| Nominal Impedance | 5 Ω |
| Maximum SPL (@ 1m) | 112 dB |
| Recommended Amplifier Power | 50 – 500 W |
| Crossover Principle | 3 + ½-way |
| Crossover Frequencies | 550Hz / 3,100Hz / 15,000Hz |
| High Frequency Driver(s) | 1 x 29 mm Soft Textile Dome, 1 x 10 x 55 mm Ribbon/Planar |
| Low/Mid Frequency Driver(s) | 2 x 8" Low Frequency Drivers / 1 x 6½" Midrange Driver |
| Enclosure Type | Bass Reflex (Multilayer Laminate MDF) |
